Inlet grille in a smooth cast iron frame
D400 - heavy traffic load
| Code | KDR0M |
| Material | Cast iron |
| Weight | 141 kg |
| Norm | DIN1229, EN124-2 |
| Package | 8 ks/pal |
| Load class | Heavy traffic load |
cover without hinge, horizontal PUR shock-absorbing lining, without spring-loaded lid locking in frame
Cover
- Lid weight 90kg
Frame
- Cast iron frame
- Frame height 160 mm
- Use with BAR-V and BAR adjustment rings
- Integrated PUR damping insert with high resistance
Other
- Suitable for places with high traffic load
- The cover is supplied with a black finish
Damping insert
Hatch without hinge
rainwater drainage
