Manhole cover with ventilation in a self-leveling frame
D400 - heavy traffic load
| Code | KDN21 |
| Material | Concrete, Cast iron |
| Weight | 123 kg |
| Norm | DIN19584-2, DIN1229, EN124-2 |
| Package | 10 ks/pal |
| Load class | Heavy traffic load |
cover without hinge, horizontal PUR shock-absorbing lining on frame, EPDM shock-absorbing lining on cover, without spring-loaded lid locking in frame
Cover
- EPDM damping insert - resistant to oils
- With concrete filling with ventilation - uninteresting for thieves
- Lid weight 90kg
Frame
- Self-leveling frame with mounting for trap
- Frame height 200 mm
- Use with BAR-V and BAR adjustment rings
- Installation without guide ring - the frame can be inserted directly into the shaft
- Installation in the running layer and load transfer even outside the shaft
Other
- Suitable for places with high traffic load
- chemical resistance of concrete XF4
Damping insert
Concrete-cast iron lid
Hatch without hinge
