Manhole cover with ventilation in self-levelling frame
D400 - heavy traffic loads
| Code | KDM03 |
| Material | Cast iron |
| Weight | 112 kg |
| Norm | EN124-2 |
| Package | 10 ks/pal |
| Load class | Heavy traffic load |
cover without hinge, horizontal PUR shock-absorbing lining, without spring-loaded lid locking in frame
Cover
- Lid weight 82 kg
- Permits your own design/logo
- Cast iron without ventilation with non-slip design.
Frame
- Frame height 160mm, weight 30 kg
- Use with BAR-V and BAR adjustment rings
- Suitable for places with high traffic loads
- Integrated PUR damping insert with high resistance
- Installation in the running layer and load transfer outside the well
Other
- custom motif on the lid possible
- Hatch comes without coating – painted options can be ordered
Custom solutions
Damping insert
Hatch without hinge
