Manhole cover with ventilation in a cast iron frame with foot
D400 - light traffic load
| Code | KDL24 |
| Material | Cast iron |
| Weight | 112 kg |
| Norm | DIN1229, EN124-2 |
| Package | 10 ks/pal |
| Load class | Light traffic load |
cover without hinge, horizontal PUR shock-absorbing lining on frame, EPDM shock-absorbing lining on cover, without spring-loaded lid locking in frame
Cover
- Cast iron with ventilation and anti-slip design.
- Lid weight 90kg
- Custom theme/logo option
- EPDM damping insert - resistant to oils
Frame
- Cast iron frame with foot without shoulder for trap
- Frame height 100 mm
- Use with BAR-V and BAR adjustment rings
- Integrated PUR damping insert with high resistance
Other
- The cover is supplied without surface treatment - painted variants can be ordered
- Suitable for places with light traffic load
- custom lid motif possible
Customer solutions
Damping insert
Hatch without hinge
