Manhole cover with ventilation in the distribution frame

D400 - extreme traffic load

Code	KDJ64
Material	Concrete, Cast iron
Weight	235 kg
Norm	DIN1229, EN124-2
Package	6 ks/pal
Load class	Extreme traffic load

cover without hinge, horizontal PUR shock-absorbing lining on frame, horizontal and vertical PUR shock-absorbing lining on lid , without spring-loaded lid locking in frame

Cover

Integrated KASI-PUR damping insert with high resistance
Cast iron with ventilation and anti-slip design.
Lid weight 90kg
Custom theme/logo option

Frame

Distribution frame 1000mm with mounting for catcher
Frame height 180 mm
Use with BAR-V and BAR adjustment rings
Integrated PUR damping insert with high resistance
Three handling hinges

Other

The cover is supplied without surface treatment - painted variants can be ordered
Suitable for places with extreme traffic load
custom lid motif possible
