Manhole cover with ventilation in a square frame
D400 - heavy traffic load
| Code | KDC24 |
| Material | Concrete, Cast iron |
| Weight | 240 kg |
| Norm | DIN1229, EN124-2 |
| Package | 5 ks/pal |
| Load class | Heavy traffic load |
cover without hinge, EPDM shock-absorbing lining on cover, without spring-loaded lid locking in frame
Cover
- Cast iron with ventilation and anti-slip design.
- Lid weight 90kg
- Custom theme/logo option
- EPDM damping insert - resistant to oils
Frame
- Frame height 160 mm
- Use with BAR-V and BAR adjustment rings
Other
- The cover is supplied without surface treatment - painted variants can be ordered
- Suitable for places with high traffic load
- custom lid motif possible
Customer solutions
Hatch without hinge
